Description
49 inches waterproof digital totem
1、Characteristics of Outdoor digital totem suppliers：
We are from China
We mainly manufacture outdoor digital signs
We have 10 years of experience in the manufacture of outdoor digital signs
Our products have IP65 waterproof grade and high brightness screen display
Products can be customized according to the needs of customers
2、Product parameters：
| Model | Windows version | Android version | |
| Screen | Panel Brand | Samsung/LG/BOE Full New 100% A(optional) | |
| Panel size | 49″（19” ~86”） | ||
| Display size | 1074mm(V)×604mm(H) | ||
| Display ratio | 16:09 | ||
| Resolution | 1920*1080 | ||
| Viewing angle | 178°/178°(H/V) | ||
| Color | 16.7M | ||
| Back light | LED | ||
| Brightness | 2500 cd/m2 | ||
| Contrast ratio | 3000:01:00 | ||
| OS System | main board:i5-3317U(optional) | CPU:RK3288(optional) | |
| RAM:4G (optional) | RAM:2G | ||
| ,SSD:128G(optional) | EMMC:8G(optional) | ||
| Operation | Win7(optional,win8,win8.1,win10) | Android 6.1(optional,Android6.1/7.1.2/8.2/9.0) | |
| Connection to network | RJ45, WIFI (4G,optional) | RJ45, WIFI (4G,optional) | |
|
Touch Screen system |
Touch ways | finger,touch pen | finger,touch pen |
| Touch dots | 10dots (optional,20dots,40dots) | 10dots (optional,20dots,40dots) | |
| Durability | More than 50 million touch | More than 50 million touch | |
| Power | Power | 330W | 330W |
| Voltage | AC100-240V 50/60HZ | AC100-240V 50/60HZ | |
| Stability | good | good | |
| Instructions | Interface | VGA/HDMI/USB | HDMI/USB/SD |
| Working | -30°C — 60°C(with air condition） | -30°C — 60°C(with air condition） | |
| temperature | -10°C — 55°C(with air follow exchange） | -10°C — 55°C(with air follow exchange） | |
| -30°C — 55°C(with air follow exchange+heater) | -30°C — 55°C(with air follow exchange+heater) | ||
| Material | Aluminum alloy,tempered glass | Aluminum alloy,tempered glass | |
| Surface | Spraying,frosted aluminum | Spraying,frosted aluminum | |
| Size | Undetermined | Undetermined | |
| Weight | Undetermined | Undetermined | |
| Body | Shell | Galvanized steel sheet. Thickness:2mm. | |
| Color | Black , white , silver or customized colors | ||
| Packing | By carton, wooden case, flight case （optional） | ||
| Optional Functions | Anti-dazzle、Anti-graffiti、Anti-glare,Anti-refection、 | ||
| Anti-UV、Anti-IR、Water-proof、dust-proof、vandal proof | |||
| 3G/4G Capability | |||
| Human sensor、Light sensor、Screen sensor、Humidity sensor、Temperature sensor、 | |||
| Vibration sensor、Safty monitoring sensor、Ponding sensor、Smog sensor、Collision sensor、Tilt sensor | |||
